LIGHT SPEED ENGINEERING, LLC'S
PLASMA CDI FEATURES

No Moving Parts
Hotter Spark

Instant Start

Reduced Maintenance Down Time and Costs
Increased Fuel Efficiency
Designed Specifically for Aircraft
Easy System to Install



LSE Plasma III 7.2" x 6.4" x 1.5"
CDI Ignition Module: Weight: 1.7 lb.
Input Type: Direct Crank Triggering
Optional 4 cyl. Input Type: Accessory Case Mounted Hall Effect Sensor Module
Dual Output
Mini Ignition Coils:		 2 (4 cyl.) or 3 (6 cyl.)
Weight: 5 oz ea.
Current Consumption
(4 cyl.):		 1.3A at 13.8v
Current Consumption
(6 Cyl):		 2.1A at 13.8v
Supply Voltage: 4 to 35v
Temp Range: -40° to +200° F
Automatic Timing: 15° to 43° BTDC,  TDC for starting
Spark Energy: >120 mJ, 0-3500 rpm
Total Weight: 3 lb. (4 cyl.)
4 lb. (6 cyl.)

*Specifications subject to change without notice.

LSE Plasma II &
LSE Plasma II Plus		 6" x 5.5" x 1.5"
CDI Ignition Module: Weight: 1 lb.
Input Type: Direct Crank Triggering
Optional 4 cyl. Input Type: Accessory Case Mounted Hall Effect Sensor Module
Dual Output
Mini Ignition Coils:		 2 (4 cyl.) or 3 (6 cyl.)
Weight: 5 oz ea.
Current Consumption
(4 cyl.):		 1.2A at 13.8v
Current Consumption
(6 Cyl):		 1.9A at 13.8v
Idle Current: 0.4A at 13.8v
Supply Voltage: 4 to 35v
Temp Range: -40° to +200° F
Automatic Timing: 15° to 43° BTDC,  TDC for starting
Spark Energy: >120 mJ, 0-3500 rpm
Total Weight: 2.5 lb. (4 cyl.)
3.5 lb. (6 cyl.)

*Specifications subject to change without notice.
